How does a current voltage protector detect over - current and over - voltage situations? + Read More
| Operating Voltage(Un) | 150V-270VAC or 110VAC |
| Operating Frequency | 50/60Hz. |
| Operating Power | <6VA |
| Operating Temperature | 100mA~5.5AAC |
| Current Meas. Range | 1015A-9995/5A(...×5) |
| Current Transformer | ±1% |
| Measurement Precision | 20mm(96),14mm(72,36),9mm(48)disspiay |
| Display | Plug-in Terminal |
| Connection Type | 1.5mm² |
| Cable Diameter | <300gr. |
| Weight | 91×91mm(96), 68×68mm(72), 46×46mm(48), 31×72mm(36) |
| Panel Hole SizesMounting | Front panei mounted |
| Protection Ciass | IP41 |
| Operating Aititude | <2000 meter |
